DA Series – Voice Activated Headset Intercom System, Fixed-site application

  • Full Duplex Communication
  • Connects up to 9 Users
  • Excellent intelligibility to 116 dBC
  • Highly reliable, using centralized Power Supply
  • Can be powered by a Battery or AC Power Supply
  • Hands-Free VOX System - VOX Activation in 3ms, means no words or partial words are lost
  • Electret Noise Cancelling Boom Microphone for use to 116 dBC
  • Personal Volume Control
  • Curly Cord, SEDFLEX, Extended Length: 1.2m (4”)
  • Energy Efficient
  • 3 Year Limited Warranty
Compare

DA Series is a full-duplex, wired, industrial-grade headset intercom system with voice-activated amplifiers (VOX). The central power supply incorporates headset jacks, eliminating the need for additional junction boxes. Power can be supplied by AC or for portable use a rechargeable battery version is available.  It can also be mounted on a wall when used in a fixed site application such as a plant or factory-type setting.

The system Headsets can be equipped with either a Boom or Throat Microphone which are designed for use in high ambient noise, such as is typically experienced in machine shops, or in process control applications in factories, or at inspection points.

For the vehicular application of DA Series, click here.



Additional information

Max. Headset Connections

9

Full Duplex Communication (2-way)

Yes

VOX (Voice Activated)

Yes

Push-To-Talk (PTT)

No

Push-To-Mute (PTM)

Optional

DSP (Digital Signal Processor)

No

System Type

Wired

Radio Compatible

No

AM/FM Radio

No

Intercom Feature

Yes

Intrinsically Safe

No

Redundant Power Supply

No

Hearing Aid Compatibility

Yes

Personal Volume Control

Yes

Water-Resistant

No

RFI Immune (Radio Frequency Interference)

Yes

Transmit Power

N/A

Communication Range

N/A

Power Supply Type

Centralized – AC Mains (Standard) or Rechargeable Battery (Optional)

Battery Life

Battery (Optional)

Power Supply Range

110V – 240V AC

Low battery Indicator

Yes

Operating Temperature

-30°C to 60°C

Product Dimensions

Junction Box Size – 12”x 5.5” x 4.3”

Limited Warranty

3 Years

Encrypted

N/A

Applications

  • Non-Intrinsically safe environments
  • Maintenance locations
  • Workgroups needing co-ordination
  • Vehicle communication such as in paint trucks (See DA Series – VOX Enabled Vehicle Intercom System)

Certifications

  • Hearing Protector Rating: CSA A(L), as per ANSI S12.6-2016 (R2020)
  • ISO 9001:2015

Accessories

  • Extension Cords
  • Junction Boxes
  • Power supply, AC (standard)
  • Power supply, Rechargeable Battery (Optional)
  • Hygiene Kit
  • Wind Screens (for Boom Microphone)

Compatible Headsets

  • DA Series Headsets
