198920 – Single-Sided, Lightweight Headset with Boom Mic.

  • 330° rotating, flexible gooseneck arm ensures proper positioning of the microphone.
  • The noise-cancelling electret boom mic provides excellent voice transmission in noisy environments.
  • The microphone windscreen can be easily replaced for hygiene purposes.
  • Breathable leatherette foil on soft-foam ear cushions provides comfort and is resistant to wear and tear.
  • The adjustable headband provides users the ability to easily adjust the headset to their liking.
  • A high-quality, flame-retardant polyurethane connection cord provides superior performance.
  • 2 Year Limited Warranty



Compare

The Rescom Elite® system includes a wide range of headsets and can accommodate any type of application. All models are Intrinsically Safe. All plastics meet the requirements for ESD dissipation as per Intrinsic Safety requirements.

ABOUT 198920: The 198920 is a lightweight and intrinsically safe headset. Wear the reversible headset by rotating the gooseneck microphone for left or right-sided orientation. With a noise-cancelling electret boom mic and a speech-enhancing receiver, every word can be heard crystal clear over the background noise. Single-sided headsets allow users to maintain situational awareness while monitoring the communication between their team members.

HIGH-QUALITY SOUND: The considered selection of professional microphone & receiver elements in SED® headsets provide best-in-class voice clarity while being used in commercial environments. Unidirectional, noise-cancelling electret boom microphones and the speech-enhancing receiver can greatly highlight voice-over background noises to ensure every word is crystal clear.

SUPER COMFORTABLE: The headset ear cushion is made of skin-friendly, soft and breathable leatherette with soft-foam backing, making it comfortable for all-day long wearing comfort without pain or pressure to the ears or head.  The opposing above-the-ear pad has a soft cushion to eliminate pressure points. An adjustable headband provides Users with a perfect fit and comfort for different head sizes. The flex gooseneck microphone with positional stability ensures the arm retains its position of the microphone while in active situations.

GREAT DURABILITY: Lightweight and robust design, plastic-covered stainless steel headband, superior receiver and microphone quality. The connection cord jacket is flame-retardant polyurethane, designed to withstand harsh environments.

COMPATIBILITY AND WARRANTY: The headsets come with a 2-year Limited Warranty.

What is Intrinsically Safe?

Intrinsically Safe means that the system is incapable of causing an explosion or being a source of ignition in the presence of potentially explosive or combustible materials and gases.  In other words, the equipment and wiring are incapable of releasing sufficient electrical or thermal energy under normal or abnormal conditions to cause the ignition of a specific hazardous atmospheric mixture in its most easily ignited concentration.

Other Rescom Elite® Headsets

Rescom Elite® System

Other Intrinsically Safe Products

Additional information

Hardhat Mount

N/A

Left-Dressed Mic

Reversible

Hardhat and Left-Dressed

N/A

Special Feature

Pre-Amp

Integrated

PTT

No

Intrinsically Safe

Yes

Number of Speakers (Receivers)

Single-Sided

Watertight

No

Watertight Connectors

IP-67 (To 0.5m/20')

Personal Volume Control

No

Ear Cushion Type

Leatherette foil on foam ear cushions

Connector Type

5 pin Lemo® Push to Lock Connector

Mic. Type

Electret Boom Mic. (Hardwired)

Mic. Frequency Response

100 Hz to 5 kHz

Mic. Senstivity @1kHz

Mic. Impedance @1kHz

1K5 @ 1kHz

Battery Life (avg.)

N/A

Battery Type

N/A

Weight

230g (8 oz)

Mount

Adjustable Plastic Headband

Noise Reduction Rating (NRR)

7dB

Speakers Frequency Response

300Hz to 4kHz

Speakers Sensitivity @1kHz

73 ± 2dB

Speaker Impedance

150 Ω

Ambient Noise Levels

80dBC (118dbC with earplugs)

Connection Cord Length

2.1m (6.10ft)

Connection Cord Type

Straight

Connection Cord Material

Flame retardant polyurethane

Connection Cord Temperature Range

TBA

Connection Cord Chemical Resistance

TBA

Designed For

Standard Colours

Black

Applications

These Entity Approved headsets work with all Intrinsically Safe rated radios.

  • High Noise Environments
  • Manufacturing
  • Facility Maintenance
  • Construction
  • Machine Operations
  • Refineries
  • Breweries
  • Emergency Services
  • Search & Rescue (SAR)
  • Mining
  • Power Generation Plants
  • Agricultural
  • Aircraft
  • Maintenance
  • Underground jobs



Certifications / Safety Ratings

  • ISO 9001:2015 registered/ certified
  • CSA and UL approved as per standard #C22.2 No.157-92 and UL #913 Seventh Edition (CSA File No. 224590-1669565)
    • Class I, Div. 1 Groups A, B, C, & D
    • Class II, Div. 1Groups E, F, G
    • Class III Div. 1, Gaseous Mines

Parts & Accessories

  • Hygiene Kits
  • Wind Screen (for Boom Mic.)
  • Above-ear cushion pad
  • Leatherette foil on foam ear cushion
